System Solutions for Marking of Spectacle and Contact Lenses

System Solutions for Marking of Ophthalmic Glasses and Contact Lenses

Laser Engraving with Excimer or DPSS Lasers

The production of ophthalmic lenses requires different marking processes, e.g. technical engravings and brandings for spectacle lenses as well as UDI marking for contact lenses. 3D-Micromac offers ophthalmic marking solutions for laser engraving of all types of ophthalmic lenses, e.g. prescription and sunglasses, or contact lenses. All systems use UV lasers for permanent marking.

Laser Marking Systems for Every Requirement

3D-Micromac‘s customers can choose between premium-quality excimer laser systems and high-quality maintenance-free DPSS laser systems. Both are suitable for production of technical engravings and visible brandings on blocked and unblocked lenses as well as contact lenses.

Using the microMARK™ MCF excimer laser system, the engravings will be generated by cold laser ablation of 193 nm UV radiation. This results in a superior engraving quality considering all cosmetic aspects – without any heat affection and micro cracks. The industry-approved microMARK™ MCF system guarantees maximum throughput and availability.

With the laser system microMARK™ RXe 200, 3D-Micromac has revolutionized the efficiency of blocked lens engraving by using excimer lasers. Focus is put on unique optical set-up and engraving quality. Customers benefit from low investment and small operating costs.

In addition to the already proven excimer technology, 3D-Micromac offers the compact and maintenance-free DPSS laser system microMARK™ MCL to meet customer’s demand for high-quality marking with significantly decreased cost of ownership. The system is utilized for visible, invisible as well as for technical engravings of all kinds of spectacle lenses, including CR39, polycarbonate, high-index materials and even mineral glass. Furthermore, it is possible to mark hard and soft contact lenses. The use of a UV DPSS laser source achieves a high-quality marking result comparable to excimer laser engravings.

Industry-approved since 2004

3D-Micromac started the development of excimer laser engraving systems in 2004. With over 200 systems installed worldwide and about 80 percent global market share of all premium labeling systems for ophthalmic and contact lenses, 3D-Micromac now is the market leader in the field of ophthalmic marking systems.

The worldwide available service team of 3D-Micromac supports customers through-out the whole life cycle of their engraving systems. In addition, 3D-Micromac has a fully equipped application laboratory with experienced process engineers that support customers in feasibility tests, process development, and realization of customized solutions.

microMARK™ MCF RXe 200 – Excimer Laser System

Advanced efficiency in excimer laser marking

  • Suitable for all kinds of blocked lenses
  • High-quality engraving with accurate contrast adjustment
  • Reliable process stability
  • Low investment and operating costs
  • Smallest excimer laser system footprint available on the market

Productivity: 150 blocked lenses per hour with automatic handling

microMARK™ MCF – Excimer Laser System

Premium-quality marking for spectacle and contact lenses

  • Suitable for technical and decorative engravings (branding) on all kinds of lenses and coatings including UDI marking on hard and soft contact lenses
  • Maximum throughput by automatic handling
  • Superior availability by second laser source

Productivity: Up to 200 blocked lenses or 120 unblocked lenses per hour with automatic handling in microMARK™ MCF MP version

microMARK™ MCL – Maintenance-free DPSS UV Laser System

  • Suitable for branding and technical marking of spectacle lenses as well as technical and UDI marking of hard and soft contact lenses
  • High-quality DPSS laser engraving
  • Low investment and operating costs, maintenance-free
  • Easy retrofitting of automated handling system at customer’s site

Productivity: Up to 150 blocked lenses per hour with automatic handling system
